B&C DE82 BULLET TWEETER

B&C DE82 BULLET TWEETER Features 160 W continuous program power capacity 1.4″ horn throat diameter 75 mm (3 in) aluminium voice coil Titanium diaphragm 500 – 18000 Hz response 107 dB sensitivity Shorting copper cap for extended HF response Specifications Throat Diameter 36 mm (1.4 in) Minimum Impedance 8 Ω Continuous Power Handling 160 W Frequency Range 0.5 kHz – 18 kHz Voice Coil Diameter 75 mm (3 in) Inductance 0.14 mH Flux Density 1.8 T Min Frequency Range 0.5 kHz Nominal Impedance 8 Ω Nominal Power Handling 80 W Sensitivity 107 dB Recommended Crossover 1 kHz Winding Material Aluminium Diaphragm Material Titanium Max Frequency Range 18 kHz Mounting and Shipping Info Other details 4x M6 Mounting Studs with bolts and washers included Depth 64 mm (2.52 in) Shipping Units 1 pcs Shipping Box 190x190x80 mm (7.48×7.48×3.15 in) Overall Diameter 170 mm (6.69 in) Net Weight 4.44 kg (9.79 lb) Shipping Weight 4.56 kg (10.05 lb) Service Kit hf Replacement Diaphragm MMD3A8
